Start of the EU Project MUNDFAB

Press Release / October 16, 2020

The progressing development of big data and mobility applications as well as of the Internet of Things requires the further miniaturization of electronic circuits. Sophisticated manufacturing techniques for computer chips, such as the sequential 3D integration of devices, are a key to success. In addition to experimental investigations, the use of simulation programs is of particular importance: Simulations allow significant cost and time savings in the development of new technologies and devices. The improvement of simulation tools is therefore the key focus of the EU project MUNDFAB („Modeling Unconventional Nanoscaled Device FABrication“) coordinated by Fraunhofer IISB (Erlangen, Germany).

© CNR-IMM
Kinetic Monte Carlo atomistic simulation of the growth process of a silicon carbide nanoparticle. The figure on the left shows the surface atoms of the nanoparticle, while the figure on the right highlights various stacking defects that were generated during the growth process. The nanoparticle has a size of about 50 nm.

Simulation programs based on classical continuum approaches are of limited use for nanometer-sized structures such as investigated in MUNDFAB. This is because they are not able to accurately predict relevant effects, for instance the reduced electrical activation of dopants, special cases of topography modifications, or the formation and growth of defects. In particular, existing models do not allow the precise simulation of low-temperature processes, which are essential for the sequential 3D integration of devices.

This is where the MUNDFAB project comes in: In order to optimize modeling for an accurate prediction of the processing of, e.g., silicon or silicon-germanium layers used for nano-sized devices, dedicated experiments are carried out to improve the simulation models. For the simulations, the researchers use commercial software tools, open-source applications as well as simulation programs provided by the project partners, which are adapted and further developed in the project. Simulators that can directly represent the atomistic structure of the systems under consideration (the figure shows an example) allow a particularly realistic modeling of the nanostructures. The final goal of the project is to establish a completely calibrated simulation toolchain, which allows the computer-based virtualization of the manufacturing and sequential 3D integration of nano-sized devices.

In February, the project coordinator Fraunhofer IISB hosted the kick-off meeting with all partners. After this meeting, which could still be held as a face-to-face event, it was necessary to switch to virtual collaboration in the following months. For an effective communication and cooperation, the partners used various tools. The results are impressive: Four scientific papers from the project were already be presented at SISPAD 2020, the world's leading conference on the simulation of semiconductor devices and processes. This year, the conference was all-virtual and took take place from September 23 to October 6. Details are available on the MUNDFAB website (see below) under "Events".

MUNDFAB runs from January 2020 to December 2022 and receives funding within the European Union’s Horizon 2020 research and innovation programme  under grant agreement No. 871813 of 3.8 million Euros. The project partners are Fraunhofer IISB (coordinator), CEA-Leti (France), CNR-IMM (Italy), CNRS-LAAS (France), Lukasiewicz-ITME (Poland), STMicroelectronics (France) and TU Vienna (Austria).

Further information, such as publications or technical project reports, is available on the website: https://www.mundfab.eu/
